CBKP Triple External Gear Pump

Name: CBKP Triple External Gear Pump
Brand: Raj Hydraulic Works
Price: 17000 INR
Availability: InStock

Price 17000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CBKP Triple External Gear Pump Specification

Mounting Type
Flange or Foot Mounted

Speed
1000-3000 rpm (Recommended)

Features
Rugged Design, High Efficiency, Low Maintenance, Modular Construction

Discharge Pressure
Up to 250 bar (Max)

Flow Rate
20 to 150 LPM (Model dependent)

Control System
Manual/Automatic (depending on drive system)

Voltage
Not Applicable (Mechanical driven)

Frequency
Not Applicable (Mechanical drive)

Working Temperature
-10C to 80C (Typical)

Head Size
Varies with application

Theory
Triple External Gear Pump

Inlet/Outlet
Threaded or Flanged Ports (customizable sizes)

Noise Level
Low noise (75 dB at rated operation)

Max Suction
Up to 6 meters (Lift)

Caliber
Standard sizes-customizable

Material
High-grade Cast Iron/Aluminum Alloy

Structure
Gear Pump

Power
Mechanical Input (Electric motor or engine driven)

Product Type
CBKP Triple External Gear Pump

Standard
High

Fuel Type
Not Applicable (For hydraulic oil use)

Pressure
High Pressure Bar

Usage
Hydraulic Systems, Lubrication, Industrial Machinery

Application
Hydraulic Power Units, Machine Tools, Press Machines

Suction Type
Positive Displacement

Seals Type
High-Performance Nitrile or Viton Seals

Priming
Self-priming

Pump Type
Triple External Gear Pump

Capacity
20 to 150 LPM

Surface Finish
Corrosion Resistant Coating Available

Maintenance
Easy to Service, Replaceable Seals and Bearings

Rotating Direction
Clockwise or Counter-Clockwise (As per specification)

Viscosity Range
10 to 1000 cSt (Oil Viscosity Range)

Port Size
1/2" to 2" BSP/NPT/F Custom

Weight
7-25 kg (Depending on model/configuration)

Shaft Type
Keyed/Splined Shaft (Customizable)

CBKP Triple External Gear Pump Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
10 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About CBKP Triple External Gear Pump

We are offering a highly efficient CBKP Triple External Gear Pump which is used for extensive application in engineering machineries. The housing is manufactured using a liquid extrusion process. The alloy steel structure ensures reliable performance and long service life. It is equipped with a sturdy bearing for resisting overload on the system. The manufacturer has used an automatic compensation mechanism in the CBKP Triple External Gear Pump to ensure efficient performance. The pump has been designed to sustain high pressure in the pumping of water, light oil, and different fluids. Check the complete details about the product and send your inquiries.
